Fabbri F240

F240 Biomass Space Heater 279kW, with flue fan. Three phase 400v.

Technical Information

Unit width 1100 mm
Unit height 2250 mm
Unit depth 1900 mm
Flue diameter 200 mm
Fuel chamber depth 1200 mm
Fuel chamber width 740 mm
Fuel chamber height 1040 mm
Ventilation fan power 2.98 kW
Air delivery pipes 3 x 300 mm Ø
Air flow (at 15 °C) 17800 m3/hr
Flue fan power 0.56 kW
Ventilation exit static pressure 160pa
Electricity supply 10amps supply 5 amps per phase
Fuel consumption @ 20% moisture 83Kg per hour

Can I burn any type of wood?

No. You can only burn dry or seasoned wood. You must not use painted, treated wood, sawdust or wood containing foreign objects or glue, which includes ply and MDF. Burning these items may cause damage to your Fabbri and the environment. However you can use any other type of dry or seasoned wood, such as off cuts, broken pallets, waste wood, split logs, pellets, briquettes as well as small quantities of paper and cardboard mixed with wood.
