Fabbri F120

F120 Biomass Space Heater 140kW, with flue fan. Three Phase 400v.

Technical Information

Unit width 930 mm
Unit height 1970 mm
Unit depth 1700 mm
Flue diameter 200 mm
Fuel chamber depth 950 mm
Fuel chamber width 600 mm
Fuel chamber height 860 mm
Ventilation fan power 2.24 kW
Air delivery pipes 3 x 250 mm Ø
Air flow (at 15 °C) 8900 m3/hr
Flue fan power 0.56 kW
Ventilation exit static pressure 160pa
Electricity supply 10amps supply 4 amps per phase
Fuel consumption @ 20% moisture 43Kg per hour

Can I burn any type of wood?

No. You can only burn dry or seasoned wood. You must not use painted, treated wood, sawdust or wood containing foreign objects or glue, which includes ply and MDF. Burning these items may cause damage to your Fabbri and the environment. However you can use any other type of dry or seasoned wood, such as off cuts, broken pallets, waste wood, split logs, pellets, briquettes as well as small quantities of paper and cardboard mixed with wood.
