Fabbri F55

F55 Biomass Space Heater 64kW. Single phase 230v. Available with flue fan (F55CV) or without flue fan (F55SV).

We have the F55CV, with fan assisted flue, working in our warehouse as a demonstration model - to see it working please give us a call before coming in and we can make sure it is working when you are here.


Technical Information

Unit width - 700mm
Unit height 1550 mm
Unit depth 1150 mm
Flue diameter 180 mm
Fuel chamber depth 660 mm
Fuel chamber width 480 mm
Fuel chamber height 600 mm
Ventilation fan power 0.26 kW
Air delivery pipes 2 x 200 mm Ø
Air flow (at 15 °C) 3500 m3/hr
Flue fan power (CV only) 0.26 kW
Ventilation exit static pressure 160pa
Electricity supply Single phase
Fuel consumption @ 20% moisture 20Kg per hour

Can I burn any type of wood?

No. You can only burn dry or seasoned wood. You must not use painted, treated wood, sawdust or wood containing foreign objects or glue, which includes ply and MDF. Burning these items may cause damage to your Fabbri and the environment. However you can use any other type of dry or seasoned wood, such as off cuts, broken pallets, waste wood, split logs, pellets, briquettes as well as small quantities of paper and cardboard mixed with wood.
