Fabbri F85

F85 Biomass Space Heater 93kW.  Three phase 400v.  Available with flue fan (F85CV) or without flue fan (F85SV).

Technical Information

Unit width 800 mm
Unit height 1760 mm
Unit depth 1280 mm
Flue diameter 180 mm
Fuel chamber depth 750 mm
Fuel chamber width 560 mm
Fuel chamber height 700 mm
Ventilation fan power 1.12 kW
Air delivery pipes 2 x 250 mm Ø
Air flow (at 15 °C) 6300 m3/hr
Flue fan power (CV only) 0.26 kW
Ventilation exit static pressure 160pa
Electricity supply 8.5 amps supply 1.9 amps per phase
Fuel consumption @ 20% moisture 30Kg per hour

Can I burn any type of wood?

No. You can only burn dry or seasoned wood. You must not use painted, treated wood, sawdust or wood containing foreign objects or glue, which includes ply and MDF. Burning these items may cause damage to your Fabbri and the environment. However you can use any other type of dry or seasoned wood, such as off cuts, broken pallets, waste wood, split logs, pellets, briquettes as well as small quantities of paper and cardboard mixed with wood.
